Vulcan VG40 Gas 40-Gallon Manual Tilting Braising Pan - 120,000 BTU

Contact Us for Pricing? Please fill out the form below to receive a personalized quote.
* Email:
Shipping Address:

Need Help?
Contact one of our experts.

Product Overview

Vulcan's popular commercial V Series braising pans offer more standard features than the competition, including stainless steel fully-welded one-piece design with coved corners and satin finish (interior and exterior).

  • Watertight controls and enclosure
  • Electronic ignition (gas models)
  • Stainless steel cooking pan with embossed gallon and liter markings
  • Perforated pouring lip strainer included
  • Stainless steel spring assist cover with wrap around cool-to-the-touch handle and condensate lip
  • Solid state temperature controls adjust from 50°F - 425°F
  • "L" faucet bracket adds 3" to width, field installed left or right side
Model VG40
Width 46 inches
Depth 50.1 inches
Height 40.5 inches
Height (Lid Open) 70 inches
Power Type Natural Gas
Total BTU 120,000 BTU/hr
Cooking Area 39 x 23 inches
Capacity 40 gal. / 152 L
Number of Servings (4 oz.) 1,280
Tilt Operation Manual
Temperature Range 50°F - 425°F
Gas Inlet Size 3/4 inches
Installation Type Floor
Material Stainless Steel
Type Gas Braising Pan
  • UL Classified EPH Complies with UL safety standards and ANSI/NSF standards.
  • CSA Design Certified Certified by the Canadian Standards Association and meets applicable US standards for gas-fired items.
  • CSA Blue Flame Certified Certified by the Canadian Standards Association and meets Canadian standards for gas-fired items.
  • 3/4" Gas Connection This unit uses a 3/4" gas inlet connection.
