Southbend Ultimate S60DD-2G 60" Natural Gas 6-Burner Range - 168,000 BTU
Product Overview
- 60-3/4" wide open top with stainless steel front, sides and removable shelf
- 28,000 BTU Nat (24,000 BTU LP) patented, one-piece cast iron, non-clog burners
- Stainless steel front, sides and removable shelf
- 1" smooth, polished steel griddle plate with raised sides on 48" wide griddles
- 4" stainless steel front rail with closed, welded and caps
- Metal Knobs w/red stripe - Hinged, lower valve panel
- Quadrant spring doors with ergonomic chrome handle
- 6" stainless steel, adjustable legs
- Factory installed pressure regulator
Description
60-3/4” wide open top with stainless steel front, sides and removable shelf. 28,000 BTU NAt (24,000 BTU LP) PATENTED, one-piece cast iron, non-clog burners with Lifetime Warranty. Stainless steel front, sides and removable shelf. 1/2” smooth, polished steel griddle plate with raised sides on 24” and 36” wide griddles [available in manual or thermostatic,left (L) or right (R)]. 1” smooth, polished steel griddle plate with raised sides on 48” wide griddles. 4” Stainless steel front rail with closed, welded end caps. Individual, removable cast iron grate tops (rear holds up to 14” stock pot). Two (2) removable, one-piece crumb drawer under burners. Metal knobs w/ red stripe – Hinged, lower valve panel. Quadrant spring doors with ergonomic chrome handle. 6” stainless steel, adjustable legs. Factory installed pressure regulator.
Specifications
| Specifications | |
|---|---|
| Model | S60DD-2G |
| Width | 60.75 inches |
| Depth | 34 inches |
| Height | 59.5 inches |
| Weight | 1000 Lbs |
| Griddle Size | 24 inches |
| Number of Burners | 6 |
| Burner Ovens | 2 |
| Gas Inlet Size | 3/4 inches |
| Burner BTU | 28,000 BTU/Hr |
| Oven BTU | 35,000 BTU/Hr |
| Total BTU | 286,000 BTU/Hr |
| Power Type | Natural Gas |
