Biro 109PCMCONV Manual Horizontal Slicer With Conveyor
Product Overview
- Can slice up to 180 and 170 slices respectively per minute of boneless meat products
- Can raise your slicing operation to a higher level of productivity to help labor cost
- Specially designed sickle-type curved smooth blade slices the product cleanly
- Comes with conveyor
The Model 109PC Electronic Model and the Model 109PCM Mechanical Model can slice up to 180 and 170 slices respectively per minute of Boneless Meat Products. These units can raise your slicing operation to a Higher Level of Productivity to help Lower Labor Cost and Increase Profits. The specially designed sickle-type curved smooth blade slices the product cleanly (no tearing) thus increases product shelf life and reduces shrink and waste
The 109PC Electronic model operates by a 7 Programmable Keypad that controls a microprocessor. The programmable keypad allows the operator to tailor the microprocessor to your product thickness from 1/16” (1.5mm) indefinite thickness to 30” (762mm) max., reducing the time to change product thickness and operator training. Product pusher automatically returns to home position after the last slice.
The 109PCM Mechanical model can slice up to 170 fresh Boneless Meat Products per minute. This Mechanical version operates via a preset Indexing Thickness screw type Mechanism that produces a same slice thickness the full length of the product. The machine can be stopped in process and a different slice thickness from 1/16” (1.5mm) up to 1-1/8” (28.6mm) thick max. can be selected and then finish cutting the product at that different thickness. The product pusher is manually retracted just enough to accomodate the length of the next product.
| Specifications | |
|---|---|
| Model | 109PCMCONV |
| Length | 79 11/16 inches |
| Width | 33 1/2 inches |
| Height | 49 inches |
| Loading Chamber Length | 30 inches |
| Loading Chamber Width | 10 inches |
| Loading Chamber Height | 9 inches |
| Product Output | 170 Slices per minute |
| Slice Thickness | 1/16 inches to 1-1/8 inches |
| Controller | Off/On |
| Controller | Run or Jog |
| Controller | Push Button Start |
| Conveyorized Exit Chamber | 13 inches |
| Weight | 1126 lbs |
