Blodgett ZEPH-200-E-SGL Single Bakery Full Size Electric Convection Oven
Product Overview
- Exterior Construction - Full angle-iron frame Stainless steel front, top, sides and legs
- Dual pane thermal glass windows encased in stainless steel door frames
- Powder coated door handle with simultaneous door operation
- Triple-mounted pressure lock door design with turnbuckle assembly
- Removable front control panel
- Solid mineral fiber insulation at top, back, sides and bottom
- Interior Construction-Double Sided Porcelainized baking compartment liner
- Aluminized blower wheel
- Five chrome-plated racks, eleven rack positions with a minimum of 1-5/8" spacing
- Operation - Three Tubular heaters
- Solid state thermostat with temperature control range of 200F (93C) to 500F (260C)
- Two speed fan motor 1/2 horsepower blower motor with automatic thermal overload protection
Description
Full angle-iron frame Stainless steel front, top, and sides Dual pane thermal glass windows encased in stainless steel door frames Powder coated door handle with simultaneous door operation Triple-mounted pressure lock door design with turnbuckle assembly Removable front control panel Solid mineral fiber insulation at top, back, sides and bottom
Double-sided porcelainized baking compartment liner (14 gauge) Aluminized blower wheel Five chrome-plated racks, eleven rack positions with a minimum of 1-5/8” (41mm) spacing
Three tubular heaters Solid state thermostat with temperature control range of 200°F (93°C) to 500°F (260°C) Two speed fan motor 1/2 horsepower blower motor with automatic thermal overload protection Control area cooling fan Interior oven lights
Specifications
Specifications | |
---|---|
Model | ZEPH-200-E-SGL |
Length | 38.25 Inches |
Width | 36.87 Inches |
Height | 57 Inches |
Weight | 505 Lbs |
Number of Decks | 1 |
Number of Doors | 2 |
Number of Racks | 5 |
Voltage | 208 Volts |
Amperage | 51 Amps |
Wattage | 11 kW |
Hertz | 60 Hertz |
Phase | 1 Phase |
Connection | Hard Wire |
