ABM HD4000SD Patty Former Machine
Product Overview
- Stainless steel construction
- Variable productivity from 800 to 4000 patties / Hr.
- Patty thickness adjustable to 32 mm
- Features an integrated stacking service
- Conveyor belt 1220 mm
- 20L hopper capacity
- Paper attachment
- Pneumatic wire cleaner
- Support table with wheels
- Drum not included
Description
The ABM HD4000SD Patty Former Machine is an industrial-grade solution designed for maximum-volume production in large-scale food manufacturing and processing plants. This automatic, patty maker machine delivers exceptional operational speed, with variable productivity ranging up to 4,000 formed patties / Hr. The key functional feature is the integrated Stacking Device (SD), which allows the unit to run continuously or automatically stack up to 5 individual patties, a critical feature for minimizing labor.
Built for non-stop operation, the machine manages substantial raw material flow through its standard 20L hopper capacity. The machine guarantees precise portion control, offering thickness adjustment up to 1.26" (32 mm). It accommodates single patty shapes up to a maximum diameter of 5.10", allowing for consistency across various product weights.
The HD4000SD Patty Former is configured with numerous high-end components to simplify workflow and sanitation. Standard equipment includes an automatic paper attachment for packaging readiness and a pneumatic wire cleaner for continuous maintenance of the forming area. Formed patties are efficiently transferred by a long 1,220 mm conveyor belt. The entire machine is designed for tool-free dismantling, ensuring that staff can quickly and thoroughly clean all components in contact with food, thereby supporting strict hygiene compliance with minimal downtime.
Specifications
| Specifications | |
|---|---|
| Model | HD4000SD |
| Width | 32.29 Inches |
| Depth | 78.75 Inches |
| Height | 61.50 Inches |
| Paper Dimensions | 4.48 x 4.48 Inches 5.30 x 5.30 Inches |
| Conveyor Belt size | 1220 mm |
| Patty Diameter | 5.10" Single Shape |
| Number of Patties | 800 to 4000 patties / Hr. |
| Hopper Capacity | 20 L |
| Stack Capacity | Up to 5 patties |
| Wattage | 0.75 Kw |
| Installation Type | Floor |
| Paddle Material | Stainless Steel |
| Material | Stainless Steel |
| Product Type | Patty Maker |
