Turbofan EC40D7 31.9" Full Size 7 Tray Manual / Electric Combi Oven

Contact Us for Pricing? Please fill out the form below to receive a personalized quote.
* Email:
Shipping Address:

Need Help?
Contact one of our experts.

Product Overview

  • Electric Direct Steam Version
  • 7 x 1/1 GN tray capacity
  • 70mm tray spacing
  • Hand shower with fittings and connections included
  • 2 Fan speeds, low speed also reduces the heating power
  • Electronic Touch Sensitive control panel
  • High-Visibility alphanumeric LED display
  • Programmable automatic pre-heating
  • 10 pre-programmed cooking modes identifiable by instant-start icons
  • Programmable memory from mode numbers 11 to 89 in automatic sequence
  • Automatic chamber venting control
  • Timed LED cooking chamber lighting
  • Automatic Cleaning system with liquid clean system

Unit shall be a Moffat electrically heated Turbofan direct steam injection combination convection steam oven. The oven shall have a stainless steel oven chamber with 7 x 1/1 GN capacity, 12.5kW power rating and two 2 speed auto-reversing direction fans. Oven door shall be vented safe touch and feature LED oven chamber lighting. Electronic touch control panel shall provide cooking mode selection, 10 one touch favourite program keys, digital displays for temperature, time, humidity and programs, and a scrolling control knob for operation. Convection, Steam, and Combi cooking modes shall be usable in manual mode and program modes.

Unit shall be optional core temp probe ready. Unit shall include as standard a self contained Automatic cleaning system with Liquid Clean System (LCS). A water hand shower shall be included as standard. Oven shall be able to be bench mounted on 100mm feet or mounted on Turbofan oven stand model SK40A. Unit shall be supplied in 100% recyclable shipping packaging.

Model EC40D7
Width 31.9 inches
Depth 28 inches
Height 37.7 inches
Shelf Spacings 70mm
Volts 400-415V
Hertz 50 Hz
Total Hardness 60-90 ppm
Flow Pressure 200-500 kPa
Weight 198 Lbs
