Traulsen TBC5 Spec-Line Undercounter 5-Pan Blast Chiller with 6" Legs

Contact Us for Pricing? Please fill out the form below to receive a personalized quote.
* Email:
Shipping Address:

Need Help?
Contact one of our experts.

Product Overview

  • 5-pan capacity (18" x 26")
  • Left or right-hinged door
  • Three removable food probes and three timers included
  • Equipped with a set of four 6" legs
  • Intelligent touch-screen controls with automatic/manual modes
  • On-board data printer included
  • Stainless steel construction
  • 115V / 60 Hz / 1 Phase

Effectively prevent the spread of food borne illnesses caused by improper cooling with the Traulsen Spec-Line Undercounter 5-Pan Blast Chiller.

This blast chiller circulates cold air to safely and rapidly cool or freeze hot foods for storage without sacrificing the quality of the product. It’s perfect for restaurants and other commercial food service or retail establishments that require a reliable method to safely prepare “instant” or ready-to-eat meals, equip pre-cooked or pre-made foods for prolonged refrigerated storage, or even repurpose leftovers.

Simple and Intelligent Controls

Traulsen’s TBC5 blast chiller features the exclusive Epicon touch screen control panel with automatic and manual modes that make it incredibly easy to set and program. The automatic mode allows you to simply place one of the removable probes inside your hot food, close the chamber door, and wait for the chill cycle to start. After only 60 seconds, the cycle begins automatically without touching a single button. With manual mode, you can program the time and temperature of the chill cycle for specific recipe requirements. In the event that something is improperly set while in manual mode, the chiller will begin a chilling cycle within 5 minutes using default settings (if probes were used).

The Epicon control centre also includes a 90-day memory and on-board printer for storing and printing out complete HACCP documentation that can be accessed and referred to at any time.

High Quality Design and Efficient Operation

This undercounter blast chiller cycles between temperatures from 10°F to 14°F when in blast chill mode to rapidly cool products without freezing them. When freezing is required, it can cycle to temperatures as low as -25°F to effectively prevent bacteria from forming on freshly cooked products.

The unit has a stainless steel exterior front, sides, door, and top as well as a completely stainless steel interior. It’s insulated with a high-density CFC-free polyurethane insulation that’s been foamed in place inside both the cabinet and door.

The door to the blast chiller is self-closing with a stay-open feature that helps ensure it doesn’t get left open accidentally while also making it easier to load and unload large trays. The cabinet boasts 9.2 cubic feet of storage space and comes equipped with five pairs of wire tray slides. Each set can accommodate either two 12” x 20” x 2.5” pans or one 18” x 26” pan per level, providing you with plenty of space for flash freezing or flash cooling bulk products.

This Traulsen blast chiller model features a left or right-hinging door and a set of four 6-inch legs.

Specifications
Model TBC5
Width 54 inches
Depth 34.87 inches
Height 33.75 inches
Voltage 115V
Hertz 60 Hz
Phase 1 Phase
Amps 16 Amps
Capacity 9.2 cu. ft.
Pan Capacity 10 (12" x 20" x 2.5")
Pan Capacity 5 (18" x 26")
Number of Probes 3
Temperature Range -25°F - 40°F
Control Digital / Touch Screen
Casters or Legs 6" Legs
Installation Types Undercounter/Worktop
Material Stainless Steel
Type Blast Chiller
  • NSF Certified This item meets NSF's standards that focuses on public health protection, ensuring the item is designed and constructed in a way that promotes food safety.
  • Made in America This product was made in United States of America.
  • ETL Certified Determined through independent testing and periodic follow-up inspections by NRTL. This item meets North American product safety standards and published industry standards.
  • 5-20P This product comes with a NEMA 5-20P plug.
  • Spec Sheet
    Brochure
