Hobart Stero ER-76S/SC Rack Conveyor Dishwasher - 3 Phase
Product Overview
- 223 racks per hour
- Rinse 2.43 gpm /.52 gallons per rack
- Automatic fill maintains proper tank levels
- Automatic start, rack activated switch starts conveyor and pumps
- Automatic shutdown stops operation during idle periods
- 2 HP wash motor recirculating 225 gpm
Description
The STERO ER-76S/SC starts with our ER-44 and adds a powerful 32" Scrapper providing an enormous washing pattern. The scrapper does the work of a manual pre-rinsing operation stripping food soil from above and below the ware lowering detergent costs. The ER-76S/SC is ENERGY STAR® Qualified and scraps, washes, and then rinses with a 180° final rinse, creating a high volume, low water consuming washer in a 76" footprint installed in a straight line or with an optional corner loading scrapper.
The full rack-width washing pattern with our 225 gallons per minute pump powers this dishwashing workhorse. Rinsing and sanitizing are controlled by STERO’s exclusive rack-activated final rinse which guarantees accurate, trouble-free cleaning.
Easy to operate, accessibility to components for maintenance, and a basic design that produces clean dishes… that is the STERO ER-76S/SC conveyor.
Specifications
| Specifications | |
|---|---|
| Model | ER-76S/SC |
| Width | 76 inches |
| Depth | 25 inches |
| Height | 72 inches |
| Voltage | 208 V / 220 V / 480 V |
| Hertz | 60 Hz |
| Phase | 3 Phase |
| Amps | 5.4 / 11.4 / 23.5 / 53.1 Amps |
| Heating Unit | 15 kW |
| Racks per Hour | 223 |
| Water Usage | 2.43 gpm / .52 gal per rack |
| Water Temperature | Incoming water: 140°F |
| Required Final Rinse Temperature | 180°F |
| Dishwasher Type | Conveyor |
| Weight | 900 |
NSF Certified This item meets NSF's standards that focuses on public health protection, ensuring the item is designed and constructed in a way that promotes food safety.
UL Canada & USA Certified by Underwriters Laboratories, this product has been stringently tested and meets US and Canada's safety standards.
Energy Star Partner This item meets strict energy performance standards set by EPA. Highly energy efficient making it less expensive to operate.
