Thesis Handy North American Pass Through Type Dishwasher - H110E-A
Product Overview
- Basket for glasses
- Basket for 18 dishes
- 8 Division Cutlery Insert
- Integral Tank Filter
- Pass Through Dishwasher
- Handy North America
Description
The H110E-A hood-type dishwasher is the most suitable solution for establishments that have to wash different types of dishes, proving capable of washing glasses, dishes, medium-sized objects and GN 1/1 gastronorm trays in just a 620 mm width, ensuring a maximum productivity of 60 racks/hour (1080 dishes/hour). The hood-type models are fitted with an easily removable rack support for easy cleaning and a rounded moulded tank with integral filters for perfect draining and absolute hygiene. The “PUSH TO START” cycle start system ensures less waste preventing the start of empty washes.
This model is ETL and ETL Sanitation certified as it meets the requirements of the NSF/ANSI 3 rule. The washing cycles have been specifically designed to make the dishwasher compliant with the NSF hygienic safety standards, recognized by the American National Standards Institute (ANSI).
The HANDY line stands out for its wide range of models suitable for any situation. The simple electronic board control system makes it possible to set and control the rinsing and draining times and temperatures and the relevant Thermostops, crucial for ensuring excellent final results. With the control panel you can choose one of its 4 washing cycles and one automatic drain cycle (with installed drain pump), easily view on the display the tank and boiler temperature, the messages of the Self-diagnosis system and the Scheduled Maintenance warning. The smart Start button changes colour to always keep you up-to-date on the dishwasher status with the greatest ease.
The electronic control allows you to manage various parameters to give you an absolute customisation level and the continuous self-diagnosis allows you to minimise machine downtime, suggesting some operations that need to be verified. The self-cleaning cycle at the end of the day cleans the wash tank and empties the hot water from the boiler, preventing limestone from building up inside. The standard double peristaltic electric rinse-aid and detergent dispenser ensures the best result from each wash cycle with great savings thanks to the precise dosage managed by the electronic card; whereas, the moulded washing and rinsing arms ensure great reliability and durability. The Thermo-stop function checks that washing and rinsing begin only when the desired temperature is reached. The bodywork is made entirely of AISI 304 steel and has been designed with all of the components in the front for easy technical assistance. Sturdy and reliable dishwashers to best deal with every moment of your day.
Specifications
| Specifications | |
|---|---|
| Model | H110E-A |
| Height | 30.3 inches |
| Width | 56.4 inches |
| Depth | 20 inches |
| Weight | 66 Lbs |
| Tank Heating Element | 4,5kW - 37lt |
| Boiler Heating Element | 5,4kW - 7,3lt |
| Washing Pump | 1,34kW / 1,8Hp |
| Total Power Input | 6,52kW / 16A |
| Standard Input Voltage | 208V - 60Hz 230V - 60Hz |
| Recommended Inlet Water Temperature | +55C |
| Basket for glasses (Dim 500 X 500 X 100mm) | 1 |
| Basket for 18 Dishes (Dim 500 X 500 X 100mm) | 2 |
| 8 Division Cutlery Insert | 1 |
| Integral Tank Filter | 2 |
| Product Type | Single Rack Dishwasher |
